Gardner 2-Stage Rotary Vane Pump CRVpro 24 400l/min., 4 m³/h, 2x10⁻³mbar 230V, 50/60Hz CEE
Representative image only

Gardner 2-Stage Rotary Vane Pump CRVpro 24 400l/min., 4 m³/h, 2x10⁻³mbar 230V, 50/60Hz CEE

Sold by: John Morris Scientific Pty Ltd
Available Soon
Part #: 6.291 063Manufacturer #: 3242-00
Estimated shipping time:Contact us via live chat or via contact us page

$10,806.60

See the available (2) variant products
Product overview

The Gardner 2-Stage Rotary Vane Pump CRVpro 24 delivers high performance with a flow rate of 400 l/min and ultimate pressure of 2x10⁻³ mbar, making it ideal for demanding vacuum applications. Operating at 230V and 50/60Hz with a CEE connection, this robust rotary vane pump is designed for long life and reliable operation in laboratory and industrial environments.

Key Features:

  • Brand: Gardner
  • Model: CRVpro 24
  • Flow Rate: 400 l/min. (4 m³/h)
  • Ultimate Pressure: 2x10⁻³ mbar
  • Voltage/Frequency: 230V, 50/60Hz
  • Connection: CEE plug
  • Type: 2-stage rotary vane pump
  • Application: Designed for laboratory and industrial vacuum processes

Engineered by Gardner, this vacuum pump ensures powerful and consistent vacuum performance in challenging operating conditions.

Product Specifications
  • HS Code #84141025
  • Connection pressure sideKF DN 25
  • Connection suction sideKF DN 25
  • Depth206 mm
  • Dimensions (WxDxH)569 x 206 x 289 mm
  • Flow rate400 l/min
  • Height289 mm
  • Max. oil filling2200 ml
  • No. of stages2
  • TypeCRVpro 24
  • Type of auxiliary energyMains connection
  • Ultimate vacuum0.003 mbar
  • Ultimate vacuum with gas ballast0.06 mbar
  • UNSPSC41105109
  • Weight38.5 kg
  • Width569 mm
