Nabertherm Horizontal High-Temperature Tube Furnace RHTH 120/600/18/P570, Max 1800°C, Heated Length 600mm, Tube Diameter 120mm, 1 Zone, P570 Controller
Representative image only

Nabertherm Horizontal High-Temperature Tube Furnace RHTH 120/600/18/P570, Max 1800°C, Heated Length 600mm, Tube Diameter 120mm, 1 Zone, P570 Controller

Sold by: John Morris Scientific Pty Ltd
Available Soon
Part #: 4.660 573Manufacturer #: RH322V82AN
Estimated shipping time:Contact us via live chat or via contact us page

$81,894.44

See the available (17) variant products
Product overview

The Nabertherm Horizontal High-Temperature Tube Furnace RHTH 120/600/18/P570 is designed for precise heating in high-temperature applications, reaching up to 1800°C. With a 600mm heated length and a tube diameter of 120mm, this furnace accommodates larger sample sizes and is perfect for sintering, heat treatment, and other industrial and laboratory processes. The P570 controller ensures accurate temperature regulation for consistent results in demanding applications.

Key Features:

  • Brand: Nabertherm
  • Model: RHTH 120/600/18/P570
  • Temperature Range: Maximum 1800°C for high-precision processing
  • Heated Length: 600mm, suitable for larger samples and materials
  • Tube Diameter: 120mm, designed for more substantial sample processing
  • Controller: P570 for reliable and accurate temperature control
  • Applications: Ideal for sintering, heat treatment, and various high-temperature tests in industrial and laboratory settings

With the Nabertherm RHTH 120/600/18 High-Temperature Tube Furnace, you can ensure precise heat application and reliable results for various material processing and testing needs. Its robust design and advanced control system make it an excellent choice for both industrial and research applications requiring high-temperature environments.

Product Specifications
  • HS Code #85141980
  • Depth550 mm
  • Dimensions (WxDxH)920 x 550 x 640 mm
  • Power supply frequency50/60 Hz
  • Height640 mm
  • Length tube830 mm
  • Length tube heated600 mm
  • Max. ext. tube Ø120 mm
  • Max. temperature1800 °C
  • Max. voltage480 V
  • Min. voltage380 V
  • Power supply380 ... 480 V, 50/60 Hz
  • Rated capacity14400 W
  • TypeRHTH 120/600/18/P570
  • Type of auxiliary energyMains connection
  • Weight110 kg
  • Width920 mm
Downloads
  • Nabertherm High-Temperature Tube Furnaces Catalogue ExcerptDownload
