Nabertherm Horizontal High-Temperature Tube Furnace RHTH 80/3018/P570, Max 1800°C, Heated Length 300mm, Tube Diameter 80mm, 1 Zone, P570 Controller
Representative image only

Nabertherm Horizontal High-Temperature Tube Furnace RHTH 80/3018/P570, Max 1800°C, Heated Length 300mm, Tube Diameter 80mm, 1 Zone, P570 Controller

Sold by: John Morris Scientific Pty Ltd
Available Soon
Part #: 4.660 571Manufacturer #: RH282V82AN
Estimated shipping time:Contact us via live chat or via contact us page

$63,898.24

See the available (17) variant products
Product overview

The Nabertherm Horizontal High-Temperature Tube Furnace RHTH 80/3018/P570 offers precise heating for high-temperature applications with a maximum temperature of 1800°C. With a 300mm heated length and a tube diameter of 80mm, this furnace is designed for smaller to medium-sized samples, providing efficient heat treatment, sintering, and various industrial processes. The P570 controller ensures reliable temperature management for consistent results in demanding applications.

Key Features:

  • Brand: Nabertherm
  • Model: RHTH 80/3018/P570
  • Temperature Range: Maximum 1800°C, ideal for high-precision processing
  • Heated Length: 300mm, perfect for smaller sample sizes and material testing
  • Tube Diameter: 80mm, optimized for more compact sample processing
  • Controller: P570 for precise temperature regulation and easy operation
  • Applications: Ideal for sintering, heat treatment, and other high-temperature procedures in laboratory and industrial environments

With the Nabertherm RHTH 80/3018 High-Temperature Tube Furnace, you gain high-performance capabilities for a wide range of applications requiring accurate temperature control. Its advanced features, compact design, and precise control make it the ideal choice for laboratory and industrial

Product Specifications
  • HS Code #85141980
  • Depth550 mm
  • Dimensions (WxDxH)620 x 550 x 640 mm
  • Power supply frequency50/60 Hz
  • Height640 mm
  • Length tube530 mm
  • Length tube heated300 mm
  • Max. ext. tube Ø80 mm
  • Max. temperature1800 °C
  • Max. voltage480 V
  • Min. voltage380 V
  • Power supply380 ... 480 V, 50/60 Hz
  • Rated capacity9000 W
  • TypeRHTH 80/300/18/P570
  • Type of auxiliary energyMains connection
  • Weight90 kg
  • Width620 mm
Downloads
  • Nabertherm High-Temperature Tube Furnaces Catalogue ExcerptDownload
