Representative Image

Powteq Planetary Ball Mill BM40 220V, 50Hz, with 4 Grinding Stations

Brand:Powteq

Specifications

Depth: 768 mm
Dimensions (WxDxH): 645 x 768 x 621 mm
Feed particle size: 10 mm
Power supply frequency: 50 Hz
Height: 621 mm
Max. feed particle size: 10 mm
Max. final fineness: 1 µm
Max. speed: 400 1/min
Max. voltage: 220 V
Min. speed: 30 1/min

$33,640.91

Inc. GST

Available soon

Product description

The Powteq Planetary Ball Mill BM40 220V, 50Hz, with 4 Grinding Stations is a versatile and powerful milling solution for laboratory-scale grinding and mixing of samples. Designed for rapid grinding of soft, hard, brittle, and fibrous materials down to a final fineness of less than 1 µm, it is also suitable for colloid grinding. With its four grinding stations supporting up to 8 grinding bowls, the BM40 offers high throughput and consistent results. The digitally adjustable grinding time and variable sun wheel speed allow precise control, while automatic reversal of direction prevents agglomerations. Its ventilated grinding chamber cools the grinding bowls during operation, making it ideal for continuous dry and wet grinding processes across multiple scientific fields including geology, mineralogy, metallurgy, ceramics, material science, pharmacy, chemistry, and biology.

Key Features:

Brand: Powteq
Model: BM40
Power Supply: 220V, 50Hz
Grinding Stations: 4 stations supporting up to 8 grinding bowls
Grinding Time: Digitally adjustable from 0 to 999 minutes
Speed Range: Variable sun wheel speed from 30 to 400 min^-1
Operation: Suitable for dry and wet grinding, continuous operation capable
Programmable Parameters: Grinding programs can be saved and reused
Direction Control: Automatic reversal to avoid agglomerations
Cooling: Ventilated grinding chamber for bowl cooling
Control Interface: 7" LCD display with one-button operation
Safety: Safety interlock to ensure secure operation
Applications: Ideal for geology, mineralogy, metallurgy, ceramics, materials research, mechanical alloying, pharmacy, chemistry, biology, and analytical sample preparation

Scope of Supply:

Planetary Ball Mill BM40 unit with 4 grinding stations
Note: Grinding bowls and balls are not included and must be ordered separately

The Powteq BM40 Planetary Ball Mill offers precise and reliable grinding performance, making it an indispensable tool for laboratories and pilot plants requiring high-performance sample processing.

Accessories

Grinding balls

Product	Material	Ø	Mfr#	Part#	Availability	Price
Powteq Grinding Balls, 15 mm ø (500g), Stainless Steel	Stainless steel	15 mm	02.863.0108	4.669 611	In stock	$287.04
Powteq Grinding Balls, 5 mm ø (500g), Agate	Agate	5 mm	02.863.0130	4.669 615	In stock	$602.44
Powteq Grinding Balls, 10 mm Zirconium Oxide	Zirconia	10 mm	02.863.0143	4.669 624		$602.44
Powteq Grinding Ball, 30 mm Ø Agate	Agate	30 mm	02.863.0135	4.669 620		$70.88
Powteq Grinding Balls, 10 mm ø (500g), Agate	Agate	10 mm	02.863.0131	4.669 616		$602.44
Powteq Grinding Balls, 5 mm Stainless Steel	Stainless steel	5 mm	02.863.0104	4.669 607		$287.04
Powteq Grinding Ball, 40 mm Ø Agate	Agate	40 mm	02.863.0136	4.669 621		$97.45
Powteq Grinding Ball, 30 mm Ø Stainless Steel	Stainless steel	30 mm	02.863.0111	4.669 614		$141.75
Powteq Grinding Ball, 25 mm Ø Agate	Agate	25 mm	02.863.0134	4.669 619		$38.98
Powteq Grinding Balls, 3 mm Ø (500g), Zirconium Oxide	Zirconia	3 mm	02.863.0140	4.669 622		$496.13
Powteq Grinding Balls, 2 mm Ø (500g), Stainless Steel	Stainless steel	2 mm	02.863.0102	4.669 605		$512.07
Powteq Grinding Balls, 3 mm Ø (500g), Stainless Steel	Stainless steel	3 mm	02.863.0103	4.669 606		$512.07
Powteq Grinding Ball, 25 mm Ø Stainless Steel	Stainless steel	25 mm	02.863.0110	4.669 613		$70.88
Powteq Grinding Balls, 10 mm ø (500g) Stainless Steel	Stainless steel	10 mm	02.863.0106	4.669 609		$287.04
Powteq Grinding Ball, 20 mm ø Agate	Agate	20 mm	02.863.0133	4.669 618		$38.98
Powteq Grinding Ball, 15 mm ø Agate	Agate	15 mm	02.863.0132	4.669 617		$38.98
Powteq Grinding Balls, 12 mm ø (500g), Stainless Steel	Stainless steel	12 mm	02.863.0107	4.669 610		$287.04
Powteq Grinding Balls, 5 mm ø (500g), Zirconium Oxide	Zirconia	5 mm	02.863.0141	4.669 623		$602.44
Powteq Grinding Ball, 20 mm Ø, Zirconium Oxide	Zirconia	20 mm	02.863.0145	4.669 626		$116.94
Powteq Grinding Balls, 1 mm ø (500g), Stainless Steel	Stainless steel	1 mm	02.863.0101	4.669 604		$556.37
Powteq Grinding Ball, 20 mm ø Stainless Steel	Stainless steel	20 mm	02.863.0109	4.669 612		$28.35
Powteq Grinding Ball, 15 mm Ø, Zirconium Oxide	Zirconia	15 mm	02.863.0144	4.669 625		$102.77
Powteq Grinding Balls, 7 mm Ø (500g), Stainless Steel	Stainless steel	7 mm	02.863.0105	4.669 608		$287.04

Accessories for Planetary Ball Mill BM40

Product	Description	For	Mfr#	Part#	Price
Powteq Aeration Lid for Jars, 500ml Zirconium Oxide	Aeration lid for 500 ml jars, zirconium oxide	BM40	02.864.0043	4.669 575	$2,677.31
Powteq Aeration Lid for Jars, 500ml Stainless Steel	Aeration lid for 500 ml jars, stainless steel	BM40	02.864.0042	4.669 574	$1,564.57
Powteq Aeration Lid for Jars, 125ml Agate	Aeration lid for 125 ml jars, agate	BM40	02.864.0050	4.669 569	$1,474.20
Powteq Aeration Lid for Jars, 250ml Stainless Steel	Aeration lid for 250 ml jars, stainless steel	BM40	02.864.0039	4.669 571	$1,564.57
Powteq O-Ring for Grinding Jars of Agate/Zirconium Oxide, 125ml (Big)	O-ring for 125 ml jars made of agate and zirconium oxide (big)	BM40	70.011.0004	4.669 578	$24.81
Powteq Aeration Lid for Jars, 250ml Agate	Aeration lid for 250 ml jars, agate	BM40	02.864.0056	4.669 572	$1,564.57
Powteq Aeration Lid for Jars, 250ml Zirconium Oxide	Aeration lid for 250 ml jars, zirconium oxide	BM40	02.864.0041	4.669 573	$2,677.31
Powteq O-Ring for Grinding Jars of Tungsten Carbide, 125ml (Small)	O-ring for 125 ml jars made of tungsten carbide (small)	BM40	70.011.0017	4.669 579	$24.81
Powteq O-Ring for Grinding Jars, Agate/Sintered Aluminum Oxide/Zirconium Oxide, 500ml (Big)	O-ring for 500 ml jars made of agate, aluminium oxide and zirconium oxide (big)	BM40	70.011.0011	4.669 586	$24.81
Powteq Aeration Lid for Jars, 125ml Stainless Steel	Aeration lid for 125 ml jars, stainless steel	BM40	02.864.0049	4.669 568	$1,474.20
Powteq O-Ring for Grinding Jars of Agate/Zirconium Oxide, 125ml (Small)	O-ring for 125 ml jars made of agate and zirconium oxide (small)	BM40	70.011.0003	4.669 577	$24.81
Powteq O-Ring for Stainless Steel Grinding Jars, 125ml	O-ring for 125 ml jars made of stainless steel	BM40	70.011.0002	4.669 576	$24.81
Powteq O-Ring for Stainless Steel Grinding Jars, 500ml	O-ring for 500 ml jars made of stainless steel	BM40	70.011.0012	4.669 584	$24.81
Powteq O-ring for Grinding Jars, Agate/Sintered Aluminum Oxide/Zirconium Oxide/Tungsten Carbide 250 ml (Big)	O-ring for 250 ml jars made of agate, aluminium oxide, zirconium oxide and tungsten carbide (big)	BM40	70.011.0030	4.669 583	$24.81
Powteq O-ring for Grinding Jars, Stainless Steel/Agate/Sintered Aluminum Oxide/Zirconium Oxide/Tungsten Carbide 250 ml (Small)	O-ring for 250 ml jars made of stainless steel, agate, aluminium oxide, zirconium oxide and tungsten carbide (small)	BM40	70.011.0005	4.669 582	$24.81
Powteq O-ring for Grinding Jars of Tungsten Carbide, 125 ml (Big)	O-ring for 125 ml jars made of tungsten carbide (big)	BM40	70.011.0007	4.669 580	$24.81
Powteq Aeration Lid for Jars, 125 mL Zirconium Oxide	Aeration lid for 125 ml jars, zirconium oxide	BM40	02.864.0052	4.669 570	$2,120.94
Powteq O-Ring for Grinding Jars, Agate/Sintered Aluminum Oxide/Zirconium Oxide, 500mL (Small)	O-ring for 500 ml jars made of agate, aluminium oxide and zirconium oxide (small)	BM40	70.011.0009	4.669 585	$24.81

Frequently asked questions

It is a versatile and powerful milling solution for laboratory-scale grinding and mixing of samples. Designed for rapid grinding of soft, hard, brittle, and fibrous materials down to a final fineness of less than 1 µm, it is also suitable for colloid grinding. With its four grinding stations supporting up to 8 grinding bowls, the BM40 offers high throughput and consistent results. The digitally adjustable grinding time and variable sun wheel speed allow precise control, while automatic reversal of direction prevents agglomerations. Its ventilated grinding chamber cools the grinding bowls during operation, making it ideal for continuous dry and wet grinding processes across multiple scientific fields including geology, mineralogy, metallurgy, ceramics, material science, pharmacy, chemistry, and biology.
