Nabertherm Horizontal High-Temperature Tube Furnace RHTH 80/300/17/P570, Max 1700°C, Heated Length 300mm, Tube Diameter 80mm, 1 Zone, P570 Controller
Product overview
The Nabertherm Horizontal High-Temperature Tube Furnace RHTH 80/300/17/P570 offers exceptional high-temperature performance, reaching up to 1700°C. With a 300mm heated length and 80mm tube diameter, this tube furnace is perfect for precise sintering, heat treatment, and material analysis. The advanced P570 controller ensures accurate temperature regulation, providing reliable results for various industrial and laboratory applications.
Key Features:
- Brand: Nabertherm
- Model: RHTH 80/300/17/P570
- Temperature Range: Maximum 1700°C for high-precision material processing
- Heated Length: 300mm, ideal for smaller sample processing
- Tube Diameter: 80mm, designed to accommodate medium-sized samples
- Controller: P570 for accurate and reliable temperature control
- Applications: Ideal for sintering, heat treatment, and testing in demanding high-temperature environments
The Nabertherm RHTH 80/300/17 High-Temperature Tube Furnace is built for reliability and precision. Whether you’re working with materials that require temperatures up to 1700°C or need efficient heating for various processes, this furnace is an ideal solution for both laboratory and industrial settings.
Frequently Asked Questions
1. What is the Nabertherm Horizontal High-Temperature Tube Furnace RHTH 80/300/17/P570, Max 1700°C, Heated Length 300mm, Tube Diameter 80mm, 1 Zone, P570 Controller used for?
It offers exceptional high-temperature performance, reaching up to 1700°C. With a 300mm heated length and 80mm tube diameter, this tube furnace is perfect for precise sintering, heat treatment, and material analysis. The advanced P570 controller ensures accurate temperature regulation, providing reliable results for various industrial and laboratory applications.
2. Is this product suitable for sintering, heat treatment, and testing in demanding high-temperature environments?
Yes. It is designed for sintering, heat treatment, and testing in demanding high-temperature environments, and offers a heated length of 300mm, ideal for smaller sample processing and a tube diameter of 80mm, designed to accommodate medium-sized samples to support this kind of work.
3. What heated length and tube diameter does this product have?
It has a heated length of 300mm, ideal for smaller sample processing and a tube diameter of 80mm, designed to accommodate medium-sized samples.
4. What temperature range and controller does this product offer?
It offers maximum 1700°C for high-precision material processing, P570 for accurate and reliable temperature control, tmax 1600 °C, 1700 °C or 1800 °C and MoSi2 heating elements, mounted vertically for easy replacement.
Product Specifications
- HS Code #85141980
- Depth550 mm
- Dimensions (WxDxH)620 x 550 x 640 mm
- Power supply frequency50/60 Hz
- Height640 mm
- Length tube530 mm
- Length tube heated300 mm
- Max. ext. tube Ø80 mm
- Max. temperature1700 °C
- Max. voltage480 V
- Min. voltage380 V
- Power supply380 ... 480 V, 50/60 Hz
- Rated capacity9000 W
- TypeRHTH 80/300/17/P570
- Type of auxiliary energyMains connection
- UNSPSC40101805
- Weight90 kg
- Width620 mm
Products related to this item (17)
product | Mfr # | Part # | Product name | Type | Type of
auxiliary energy | Price | Availability | |
RH282V6AN3 | 9.764 561 | Nabertherm Horiz.High-Temper.Tube Furnace RHTH 80/300/16/P570 Tmax 1600°C, Including Working Tube C 799 and 2 Fibre Plugs 70x530 mm Iø x L | RHTH 80/300/16/P570 | Mains connection | €30803.30 | |||
RH322V62AN | 9.764 562 | Nabertherm HorizHigh Temperature Tube Furnace RHTH 120/600/16/P570, Tmax 1600°C, including Working Tube C-799 and 2 Fibre Plugs, 105x830 mm Ø x L | RHTH 120/600/16/P570 | Mains connection | €38914.70 | |||
RH152V62AN | 9.764 560 | Nabertherm High-Temperature Tube Furnace RHTH 50/150/16/P570, Max 1600°C, Includes Working Tube (C799) and 2 Fibre Plugs (40x380 mm Ø x L) | RHTH 50/150/16/P570 | Mains connection | €27393.30 | |||
RV152V62AN | 9.764 563 | Nabertherm High Temperature Tube Furnace RHTV 50/150/16/P570 Tmax 1600°C, Including Working Tube C 799 and 2 Fibre Plugs 40x380 mm Iø x L | RHTV 50/150/16/P570 | Mains connection | €30699.90 | |||
RH322V72AN | 4.660 572 | Nabertherm Horiz.High-Temper.Tube Furnace RHTH120/600/17/P570 Heated Length 600 mm, Tube Diameter 120 mm, 1 Zone, Tmax 1700°C, Controller P 570 | RHTH 120/600/17/P570 | Mains connection | €44205.70 | |||
RH152V82AN | 4.660 569 | Nabertherm Horiz.High-Temper.Tube Furnace RHTH 50/150/18/P570 Heated Length 150 mm, Tube Diameter 50 mm, 1 Zone, Tmax 1800°C, Controller P 570 | RHTH 50/150/18/P570 | Mains connection | €33624.80 | |||
RV282V72AN | 4.660 578 | Nabertherm High-Temper.Tube Furnace RHTV 80/300/17/P570 Heated Length 300 mm, Tube Diameter 80 mm, 1 Zone, Tmax 1700°C, Controller P 570 | RHTV 80/300/17/P570 | Mains connection | €37577.10 | |||
RV282V62AN | 9.764 564 | Nabertherm High Temperature Tube Furnace RHTV 80/300/16/P570 Tmax 1600°C, Including Working Tube C 799 and 2 Fibre Plugs 70x530 mm Iø x L | RHTV 80/300/16/P570 | Mains connection | €33315.70 | |||
RV322V82AN | 4.660 577 | Nabertherm High-Temperature Tube Furnace RHTV 120/600/18/P570, Max 1800°C, Heated Length 600mm, Tube Diameter 120mm, 1 Zone, P570 Controller | RHTV 120/600/18/P570 | Mains connection | €52185.10 | |||
RH152V72AN | 4.660 568 | Nabertherm High-Temperature Tube Furnace RHTH 50/150/17/P570, Max 1700°C, Heated Length 150mm, Tube Diameter 50mm, 1 Zone, P570 Controller | RHTH 50/150/17/P570 | Mains connection | €30743.90 | |||
RV152V82AN | 4.660 575 | Nabertherm High-Temperature Tube Furnace RHTV 50/150/18/P570, Max 1800°C, Heated Length 150mm, Tube Diameter 50mm, 1 Zone, P570 Controller | RHTV 50/150/18/P570 | Mains connection | €35005.30 | |||
RV282V82AN | 4.660 579 | Nabertherm High-Temperature Tube Furnace RHTV 80/300/18/P570, Max 1800°C, Heated Length 300mm, Tube Diameter 80mm, 1 Zone, P570 Controller | RHTV 80/300/18/P570 | Mains connection | €41456.80 | |||
RV322V72AN | 4.660 576 | Nabertherm High-Temperature Tube Furnace RHTV 120/600/17/P570, Max 1700°C, Heated Length 600mm, Tube Diameter 120mm, 1 Zone, P570 Controller | RHTV 120/600/17/P570 | Mains connection | €45733.60 | |||
RH322V82AN | 4.660 573 | Nabertherm Horizontal High-Temperature Tube Furnace RHTH 120/600/18/P570, Max 1800°C, Heated Length 600mm, Tube Diameter 120mm, 1 Zone, P570 Controller | RHTH 120/600/18/P570 | Mains connection | €51038.90 | |||
RH282V82AN | 4.660 571 | Nabertherm Horiz.High-Temper.Tube Furnace RHTH 80/300/18/P570 Heated Length 300 mm, Tube Diameter 80 mm, 1 Zone, Tmax 1800°C, Controller P 570 | RHTH 80/300/18/P570 | Mains connection | €39825.50 | |||
RV152V72AN | 4.660 574 | Nabertherm High-Temperature Tube Furnace RHTV 50/150/17/P570, Max 1700°C, Heated Length 150mm, Tube Diameter 50mm, 1 Zone, P570 Controller | RHTV 50/150/17/P570 | Mains connection | €31890.10 | |||
RV322V62AN | 9.764 565 | Nabertherm High-Temperature Tube Furnace RHTV 120/600/16/P570, Max 1600°C, Includes Working Tube C799 and 2 Fibre Plugs (105x830 mm Ø x L) | RHTV 120/600/16/P570 | Mains connection | €41883.60 |
