KNF SIMDOS 02 Diaphragm Dosing Pump U FEM 1.02 FT.18S US-Plug - 115V/60HZ
Sold by: John Morris Scientific Pty Ltd
Available Soon
Part #: 4.686 746Manufacturer #: U164970/165467
Estimated shipping time:Contact us via live chat or via contact us page
Product overview
The KNF SIMDOS 02 Diaphragm Dosing Pump U FEM 1.02 FT.18S with US-Plug (115V/60HZ) is a precise and reliable pump designed for controlled dosing of liquids in laboratory and industrial applications. Featuring a diaphragm mechanism, this dosing pump ensures accurate volume delivery and long service life. Its compact design and easy installation make it ideal for continuous operation and chemical compatibility.
Key Features:
- Brand: KNF
- Model: SIMDOS 02 U FEM 1.02 FT.18S
- Voltage: 115V / 60HZ with US plug
- Type: Diaphragm dosing pump
- Application: Precise dosing of liquids in lab and industrial settings
- Durability: Robust design for reliable long-term use
This KNF dosing pump is an essential tool for laboratories and industries requiring precise and efficient fluid dosing.
Product Specifications
- HS Code #84135040
- Depth150 mm
- Dimensions (WxDxH)93 x 150 x 144 mm
- Dosing volume0.03 ... 999 ml
- Flow rate0.03 ... 20 ml/min
- Power supply frequency60 Hz
- Height144 mm
- IP codeIP 65
- Liquid temperature5 ... 80 °C
- Material headPTFE
- Max. dosing volume999 ml
- Max. liquid temperature80 °C
- Max. operating pressure6 bar
- Max. suction height2000 mm
- Max. voltage115 V
- Min. dosing volume0.03 ml
- Min. liquid temperature5 °C
- Plug typeUS
- Power supply115 V, 60 Hz
- TypeU FEM 1.02 FT.18S
- Type of auxiliary energyMains connection
- UNSPSC41105105
- Weight0.9 kg
- Width93 mm
Variant products
Products related to this item (6)
product | Mfr # | Part # | Product name | Plug type | Type | Price | Availability | |
166072/165467 | 9.880 567 | KNF SIMDOS 02 Membrane Dosing Pump FEM 1.02 TT.18 S | EU/UK/CH | FEM 1.02 TT.18S | $3,469.88 | |||
166259/165467 | 7.643 148 | KNF SIMDOS 02 Membrane Dosing Pump FEM 1.02 ST.18 S | EU/UK/CH | FEM 1.02 ST.18S | $7,336.84 | |||
166071/165467 | 9.880 565 | KNF SIMDOS 02 Membrane Dosing Pump FEM 1.02 KT.18 S | EU/UK/CH | FEM 1.02 KT.18S | $3,237.37 | |||
164970/165467 | 9.880 569 | KNF SIMDOS 02 Membrane Dosing Pump FEM 1.02 FT.18 S | EU/UK/CH | FEM 1.02 FT.18S | $5,961.40 | |||
U166072/165467 | 4.686 748 | KNF SIMDOS 02 Diaphragm Dosing Pump U FEM 1.02 TT.18S US-Plug - 115V/60HZ | US | U FEM 1.02 TT.18S | $4,739.79 | |||
U166071/165467 | 4.686 747 | KNF SIMDOS 02 Diaphragm Dosing Pump U FEM 1.02 KT.18S US-Plug - 115V/60HZ | US | U FEM 1.02 KT.18S | $4,423.21 |
